SH-350DM

SH-350DM

Standard Features
  • Key Features and Advantages
  • Rigid Dual-Column Structure – Enhances stability and cutting accuracy, reducing vibration.
  • Adjustable Cutting Speed – Allows fine-tuning for different materials and extends blade life.
  • Easy-to-Use Interface – Simple controls with quick blade tension adjustments for improved efficiency.
  • Heavy-Duty Construction – Built with high-strength materials to withstand continuous operation.
  • Safety Features – Includes emergency stop and protective guards for operator safety.
  • Industry 4.0 Integration (Optional) – Enables smart monitoring and automated data tracking.
  • Applicable Industries
  • Aerospace – Cutting titanium and aluminum alloys for aircraft parts.
  • Automotive – Used for chassis, engine parts, and transmission components.
  • Construction – Processes steel beams, pipes, and building structures.
  • Metalworking – Supports custom metal fabrication for industrial tools and machinery.
  • Oil & Gas – Cuts pipeline sections, valves, and drilling equipment.
  • Shipbuilding – Shapes thick steel plates for marine applications.
  • Renewable Energy – Processes materials for solar panels and wind turbines.
Get a Quote
Type of Saw
  • Horizontal
Automation
  • Semi-Automatic
Miter
  • Double Miter
Production Line
  • Horizontal-Mitering
  • Horizontal-Pivot
Capacity-Max. Height (mm)
  • ≦200
Capacity-Max. Width/Throat (mm)
  • ≦350
Capacity-Round (mm)
  • 260
Blade / Circular Saw Width (mm)
  • 27
Blade Speed Min.~Max. (M/min)
  • 18~27
Angle of swivel Min.~Max. (゚)
  • 0~60
Model SH-350DM
Name Semi-auto Swivel Head Double-Mitering Band Saw
Capacity Max. (Miter) Angle ±45° +60°
Round 260 mm (10.2 in.) 200 mm (7.8 in.) 140 mm (5.5 in.)
Square 200 mm (7.8 in.) 200 mm (7.8 in.) 140 mm (5.5 in.)
Rectangular (H x W) 200 x 350 mm
(7.8 x 13.7 in.)
200 x 245 mm
(7.8 x 9.6 in.)
140 x 140 mm
(5.5 x 5.5 in.)
Bundle Cutting Front Top Clamp - - -
Rear Top Clamp - - -
Saw Blade Speed 18 - 87 m/min (60 - 285 ft/min)
Dimension (L x W x T) 3,055 x 27 x 0.9 mm (120.2 x 1 x 0.035 in.)
Tension Manual
Guide Interchangeable tungsten carbide
Cleaning Steel wire brush
Electricity Output Saw Blade Motor 2 HP (1.5 kW)
Hydraulic Pump 1/4 HP (0.18 kW)
Coolant Pump 1/8 HP (0.09 kW)
Fluid Tank
UNIT: L
Hydraulic Fluid 5.5 L (1.4 gal)
Coolant Fluid 17 L (4.4 gal)
Vise Clamping Control Method Manual
Minimum Clamping Capacity -------------------------
Remnant Length -------------------------
Feeding Control Method Manual
Single Stroke -------------------------
Multiple Stroke 99 M or 999 in.
Workbed Height 1000 mm (39.3 in.)
Weight Capacity -------------------------
Weight Net Weight 460 kg (1,014 lb)
Gross Weight 550 kg (1,212 lb)
Floor Space (L x W x H) 1,661 x 1,844 x 1,962 mm (65 x 72 x 7 in.)

*We reserve the right to modify the specification and design of machine without prior notice.
